Low Order Harmonic Suppression in Induction Motor Drives with Dodecagonal Voltage Space Vectors
The ECE Dept. Concordia University Student Branch, Industrial Applications Society Chapter, Power & Energy Society Chapter, Power Electronics Society Chapter, and Industrial Electronics Society Chapter cordially invite you to a technical seminar presented by Prof. K Gopakumar , Professor, Chairman of Electronic Systems Engineering Department at the Indian Institute of Science (IISC) . Please register using the link provided below.
Abstract
Multilevel inverters are preferred for variable speed drives due to its improved output voltage profile , less low order harmonic content and low dv/dt requirements for the devises etc;. But the conventional multilevel voltage space vector structure has a hexagonal profile and it introduces the low order 5th and seventh harmonics especially in the overmodulation region. In this respect dodecagonal voltage space vector structure with increased modulation range and suppression of the fifth and seventh order harmonics is a viable alternative for the conventional hexagonal structure for the voltage space vector structure, for PWM control. The dodecagonal voltage space vector structure generation for an induction motor drive with a split-phase structure will be introduced in the first part of the lecture and then it will be extended to the normal three phase IM drive using a switched capacitive H-bridge acting as a 5th and 7th order harmonics, throughout the modulation range, in this talk. The switched capacitive filter with a capacitive fed H-bridge will only supply reactive energy and the capacitor voltage can be balanced during the PWM control without any complexity. This will also enable the main inverter, delivering the active power to the load, to be switched with low PWM switching frequency.
Date and Time
Location
Hosts
Registration
- Date: 05 Apr 2017
- Time: 10:30 AM to 11:30 AM
- All times are (GMT-05:00) Canada/Eastern
-
Add Event to Calendar
- 1515 Rue Sainte-Catherine Ouest
- Concordia University
- Montréal, Quebec
- Canada H3G 2W1
- Building: EV Building
- Room Number: 3.309
- Click here for Map
- Contact Event Host
-
Co-sponsored by:
- Department of ECE, Concordia Student Branch
- IAS Montreal Chapter
- PES Montreal Chapter
- PELS Montreal Chapter
- IES Montreal Chapter
- IEEE Montreal Section
- Starts 15 February 2017 12:00 AM
- Ends 05 April 2017 12:00 PM
- All times are (GMT-05:00) Canada/Eastern
- No Admission Charge
Speakers
Dr. K Gopakumar FIEEE , FIETE , FNAE Professor Chairman Department of Electronic Systems Engineering Indian Institute of Science (IISC) Bangalore 560012, India
Biography:
Dr. K Gopakumar received his B.E. (Electrical Engineering) degree from Indian Institute of Science in 1980. Later on, he did his M. Sc. (Eng.) (E.E.) in 1984 and Ph.D. (E.E.) in 1994 both from the Indian Institute of Science respectively. His thesis title for M.Sc. was "A Series Dual Current Source Inverter fed Split-Phase Induction Motor Drive" and thesis title for Ph.D. was "Study on Voltage Source Inverter fed Drives for Induction Motor with Split Phase Windings".
Dr. Gopakumar is currently a Professor at the Department of Electronic Systems Engineering (formerly CEDT- Centre for Electronics Design and Technology (CEDT), at Indian Institute of Science (IISc), Bangalore, India. He is also the member of the following professional bodies:
Fellow IEEE
Fellow IETE (India)
Fellow Indian National academy of Engineers (FNAE)
Associate Editor- IEEE Trans. On Industrial Electronics
IETE (India)- B.K Bose award for contributions to the area of power electronics and drives for high power
applications
Distinguished Lecturer-IEEE Industrial Electronics Society
For additional information please contact
| Dr. P. Pillay (514) 848-2424x3108 pragasen.pillay@concordia.ca |
Dr. Akshay K. Rathore (514) 848-2424x4486 akshay.rathore@concordia.ca |
Dr. Maher Al-Badri (514) 848-2424x7087 maher.albadri@concordia.ca |
