PES Seminar on Induced Voltage & Current Analysis for Transmission Lines in Close Proximity
Title: Induced Voltage & Current Simulations, Safety Criterion, and Mitigation for EHV Transmission Lines in Close Proximity
This seminar will be given by Dr. Xuan Wu from American Electric Power, who is also the current chair of IEEE PES Columbus Chapter. 1.0 hour of CPD credit will be provided to attendees as needed.
Abstract: One of the benefits of double-circuit transmission lines is that line maintenance work can be performed on a deenergized circuit while the other circuit remains energized. However, induced voltages and currents can be generated on the de-energized line due to electrostatic and/or electromagnetic coupling effects and the close proximity to energized conductors. In order to mitigate the safety concern related to high induced voltages or currents, line discharging grounding switches (LDGS) may be installed. Since this can be an expensive solution, the magnitude of induced voltage and current is the key for defining safety criteria to judge whether or not a costly mitigation plan is needed. This paper presents the theory of induced voltage and current and a sensitivity analysis of influential parameters that impact each. In addition, a safety criterion using arc reach calculation is proposed to determine when LDGS are required.
Date and Time
Location
Hosts
Registration
- Date: 28 Feb 2019
- Time: 05:30 PM to 07:00 PM
- All times are (GMT-05:00) US/Eastern
-
Add Event to Calendar
- 700 Morrison Rd
- Gahanna, Ohio
- United States 43230
- Starts 16 February 2019 12:00 AM
- Ends 27 February 2019 04:00 PM
- All times are (GMT-05:00) US/Eastern
- No Admission Charge
Speakers
Xuan Wu of American Electric Power
Biography:
Dr. Xuan Wu is from Nanjing, China. He received the Ph.D. degree in Electrical & Computer Engineering from The Ohio State University, Columbus, in 2018 and the M.S. degree in Electrical Engineering from Arizona State University, Tempe, in 2013. Currently, he is working as a Senior Engineer at American Electric Power. His research interests include applying optimization techniques in transmission & distribution system planning, operation and market designs, electromagnetic & electrostatic coupling effects, substation fault analysis and grounding design. He has contributed to several AEP substation design guidelines and published 6 journal and more than 10 conference papers in power system areas. Xuan is an IEEE member, Chair of IEEE PES Columbus Chapter, and a Professional Engineer registered in Ohio.
Agenda
5:30 - 5:50 PM: Arrivals, refreshments (pizza or subs) & networking
5:50 - 6:00 PM: Introduction of 2019 IEEE PES ESMO Conference
6:00 - 7:00 PM: Seminar given by Dr. Xuan Wu from AEP Transmission Engineering, with time for Q&A
