Microwave assemblies are designed at increasing operating frequencies, size reduction, and a higher level of integration. Microwave filters, in the form of planar Micro-Strip, and/or Suspended-Substrate-Strip-line, consist of very thin line widths and narrow gaps, in the order of 1mil and 0.25mil respectively. With such high resolution and accuracy, Thin Film is often the technology of choice, which can deliver products in a timely manner and with high quality. A method for the design and construction of thin-film lumped-element microwave filters is presented. The resulting filters exhibit; Temperature Stability, Broadband Spurious-Free, Size Reduction, High Reliability, and Repeatability due to their thin film process on Aluminum Titanate (Al2TiO5) construction. The necessary models for inductors and capacitors are discussed. Data from Wide-Band Multiplexers and Generating Transmission zeros from All Pole structures are presented. With embedded Thin Film Resistor Technology, Non-Reflective Filters with flat Group Delay are designed and manufactured. These filters are used to reduce the overshoot and transition time of instruments and improve the pulsed performance. Thin Film Technology is currently the solution of choice enabling planar filters for 5G and Military outfits.
