Combining Metamaterials and Electromagnetic Bandgap Structures to Enable Multifunctional Compact Microwave and Millimeter-wave Circuits and Antennas
Metamaterials (MTMs) and electromagnetic bandgap structures (EBGs) are related technologies that have seen growing adoption in microwave and millimeter-wave circuits and antennas. However, the utility of the EBG bandgap often comes at the expense of the typically large EBG unit cells that limits their inclusion in highly space-constrained scenarios, e.g. within microstrip devices and antennas. On the other hand, many MTMs, such as the transmission-line (TL) MTM, afford very small unit cells through reactive loading but aren’t specifically designed to support controllable bandgap behaviour. A new technology known as the metamaterial-based electromagnetic bandgap structure (MTM-EBG) has proven successful in achieving strong and predictable bandgaps in compact microstrip structures. The bandgap behaviour is achieved in a compact fashion by embedding a multiconductor TL within the microstrip, and then using TL MTM-based reactive loading concepts to force the contradirectional coupling of supported TL modes. Importantly, the MTM-EBG is uniplanar, without vias, and can be fully printed, making it particularly useful for simple and cost-effective integration into microstrip antennas and feed networks. The utility of the MTM-EBG is further established by the fact that its dispersion properties may be rigorously and accurately designed using multiconductor TL theory, eliminating ad-hoc approaches and minimizing arbitrary tuning.
This talk will review the many examples of MTM-EBG usage in microwave and millimeter-wave circuits, antennas, and antenna systems combining MTM-EBG devices that have been demonstrated in the recent literature. These include multi-band microstrip impedance transformers, matching networks, Wilkinson power dividers, and directional couplers, as well as a variety of multi-band/multi-polarization patch antennas, all fabricated in a uniplanar, via-less, and often fully printed fashion. The talk will invoke concepts from traditional RF/microwave and antenna engineering, metamaterials, and electromagnetic bandgap structures and spans theory to numerical and experimental validation to application; importantly, it shows that the intriguing properties of metamaterials and electromagnetic bandgap structures have feasible, tangible industry applications enabling more functional and lower-cost devices for current and future microwave and millimeter-wave systems.
