AC Traction Power Protective Relaying Topics: Replacing Single-Function Relays with Multifunction Digital Relays

#electric #power #systems #vts #traction #transit #ias #pes #substations #railways #relays #Basler

The IEEE Vehicular Technology Society (VTS) Philadelphia Chapter is holding a technical meeting.  The topic is AC Traction Power Protective Relaying Topics:  Replacing Single-Function Relays with Multifunction Digital Relays.  Our speaker is Seth Nelson, Product Line Manager, Basler Electric Company.

AC traction power substations along the Northeast Corridor and Philadelphia area were originally designed using single-function electromechanical and solid-state protective relays.  Railway agencies have recently been using multifunction digital relays when upgrading substations with new protection systems or when replacing existing relays at frequency converter stations.  The existing single-function protective relays can be adjusted using a screw driver and a 4-page manual.  The new multifunction relays can be programmed from a laptop while following a 450 to 1200-page manual, depending on the vendor.  Mr. Seth Nelson will present the Basler BE1-FLEX multifunction digital relay and how it can be integrated into an existing traction power system, including recommendations on how to replace existing relay schemes.  Options to retrofit into the existing cutouts without needing to cut or replace the panel will be discussed.  A high-voltage breaker-and-a-half scheme will be used as an example.

There is no charge for meeting attendance, only for PDH certificates.

Attendees may apply for 1.0 PDH provided through the IEEE Certificates Program, accepted in all states.  Member cost is $7.00 and non-member cost is $10.00 (USD) via vTools (credit card payments are processed through PayPal).   Complete online evaluation after lecture at https://r2.ieee.org/philadelphia-vts/forms/

Payment must be received and evaluation form must be completed within three days to receive PDH certificate.

IEEE VTS Philadelphia Chapter Officers:

Chapter Chair:  Brandon S. Swartley, P.E., STV Incorporated, brandon.swartley@ieee.org
Vice-Chair:  Harvey Glickenstein, P.E., F.I.R.S.E., h.glickenstein@ieee.org
Secretary and Treasurer:  Robert Fisher, P.E., WSP, rbfisher@ieee.org

Introduction

• Overview of Basler relays
• Types of protection schemes to use on 25 Hz traction power systems
• Replacing existing schemes using multifunction relays
• Physical replacement of existing relays by replacing relay panel doors or retrofitting into existing cutouts

Questions
