Research on the Design of Multimode Dielectric Filters

#radio #frequency #multimode #dielectric #resonators #bandpass #filters
Share
     In recent years, the rapid development of modern wireless communication technologies has imposed demands for miniaturization and high performance on radio frequency (RF) front-end circuit components. Band-pass filters based on dielectric resonators have become indispensable key devices in numerous wireless communication systems due to their unique advantages such as low loss, small size, light weight, and high power handling capacity, and have continuously attracted extensive attention from scholars at home and abroad.
     Early reported single-mode dielectric resonant band-pass filters feature relatively simple structures and are easy to design. Subsequently, multimode dielectric resonators (e.g., dual-mode and triple-mode types) have gained significant popularity for their ability to further reduce the size and weight of filters. However, owing to the complex electromagnetic field distribution within multimode dielectric resonators, the mode coupling mechanism between dielectric resonators remains unclear, making it difficult to control the transmission zeros required for miniaturized high-performance band-pass filters at specified frequencies. Therefore, the precise design of multimode dielectric resonant band-pass filters remains a highly challenging research topic at present.
     This report presents an 11th-order filter designed for future wireless communication base station applications, which boasts advantages including small volume, light weight, fully controllable bandwidth, and transmission zeros. The designed filter has been fabricated and experimentally tested, and the test results are highly consistent with theoretical predictions. This further validates the design concept of high-order fully coupled controllable band-pass filters based on multimode dielectric resonators.

  Date and Time

  Location

  Hosts

  Registration


  • Add_To_Calendar_icon Add Event to Calendar

Loading virtual attendance info...

  • Contact Event Host
  • Co-sponsored by College of Electronic Science and Engineering, Jilin University; State Key Laboratory of Integrated Optoelectronics, JLU Region
  • Starts 13 December 2025 04:00 PM UTC
  • Ends 14 December 2025 04:00 PM UTC
  • No Admission Charge

  Speakers

Fan Liu of Changsha University of Science and Technology

Topic:

Research on the Design of Multimode Dielectric Filters

Biography:

Liu Fan received his Doctor of Engineering degree from the Graduate School of Science and Engineering, Saitama University (National University, Japan) in 2022, and is currently a Distinguished Associate Professor at Changsha University of Science and Technology (CSUST). He has presided over and participated in 6 projects funded by the National Natural Science Foundation of China and provincial/municipal-level programs. As the principal investigator, he has completed 3 industry-university cooperation projects with Huawei Technologies Co., Ltd. He has published more than 30 academic papers in important domestic and international journals and conferences, including papers in top journals in the microwave field such as IEEE Transactions on Microwave Theory and Techniques (IEEE T-MTT) and IEEE Microwave and Wireless Technology Letters (IEEE MWTL). He also serves as a reviewer for internationally renowned academic journals including IEEE T-MTT, IEEE MWTL, and IEEE Transactions on Antennas and Propagation (IEEE T-AP).

Address:Changsha University of Science and Technology, , Changsha, China
