PLL's and Phase Noise Modeling in Verilog
BUENAVENTURA ED/CAS CHAPTER
Verilog is the accepted language of choice for modeling and simulating digital designs. For analog blocks the tool choice is a low level circuit simulator like HSPICE or Spectre. For PLL’s a common misconception is that you can use Verilog to model a PLL if you don't care about accuracy, but if you do care about precision, you'll need an analog circuit simulator like HSPICE or Spectre. Various options like Verilog-A and Verilog-AMS are attempts to achieve the best of both worlds, but in this talk, we propose that the tool of choice for modeling and studying PLL’s and is plain “digital” Verilog. It's the right tool, but almost always used the wrong way for modeling PLL's. Understanding how the underlying simulation engine in Verilog works enables us to set up our models in a very precise, yet very simple manner. The efficiency and speed of Verilog allows us to literally watch our PLL designs come alive in the time domain with timing accuracy that can't be achieved in an analog circuit simulator. Watching designs operate in the time domain crystalizes our understanding of them, and enables us to study and quantify transient and other non-linear phenomena.
Date and Time
Location
Hosts
Registration
- Date: 22 May 2018
- Time: 06:30 PM to 08:00 PM
- All times are (GMT-08:00) US/Pacific
-
Add Event to Calendar
- Skyworks Solutions, Inc.
- 649 Lawrence Drive
- Newbury Park, California
- United States 91320
- Building: 889
- Click here for Map
- Contact Event Host
- Co-sponsored by Cristian Cismaru
- Starts 28 April 2018 11:47 AM
- Ends 22 May 2018 06:00 PM
- All times are (GMT-08:00) US/Pacific
- No Admission Charge
Speakers
Greg Warwar of Teradyne, Inc.
Biography:
Greg Warwar received a master’s degree in electrical engineering from Rice University in 1989. Following graduation, he joined Texas Instruments in Dallas, TX as a member of the technical staff where he worked on ΣΔ analog to digital converters for precision audio applications. In 1992, he joined Vitesse Semiconductor in Camarillo, CA where he worked for 23 years on high speed serial communications IC’s, focusing on many areas of analog and mixed-signal design including VCO’s, phase locked loops, clock recovery, frequency synthesizers, and adaptive equalization. Since 2015, Greg has been a principal engineer in the mixed-signal ASICs design group at Teradyne, Inc. in Agoura Hills, CA. Greg holds six U.S. patents in the area of CMOS mixed-signal IC design.
Address:Teradyne, Inc., , Agoura Hills, California, United States, 91301
Agenda
6:30-7:00pm Gather and Pizza/Refreshments
7:00-8:00pm Presentation
Co-sponsored by Skyworks Solutions, Inc.
