IEEE Swiss SSC Talks : Circuit and Device implications for Reliable Flash and Phase Change Memory
Non volatile memory is not only the ubiquitous storage medium in consumer applications but has also started to appear in enterprise storage systems as well.
Flash technology made it possible to store multiple bits in the same silicon area, thus reducing the cost per amount of data stored. However, at current sub-20nm technology nodes, flash devices fail to provide the levels of raw reliability, mainly cycling endurance, that are required by typical enterprise applications.
Advanced signal processing and coding schemes are needed to improve the flash bit error rate and thus elevate the device reliability to the desired level. In this article, we report on the use of adaptive voltage thresholds and cell-to-cell interference cancellation in the read operation of NAND flash devices.
Fields of research touch each other and overlap. Innovative material and devices such as Phase Change memory PCM has already seen 10-15 years of intense research, and recently advanced development in the labs of most memory manufacturers.
While these alternative technologies are mostly still in the basic research stage. In terms of characteristics, memristors are thought to be an eventual replacement for Flash memory due to their potentially better scalability and performance. However, their limited capability for multi-level cell storage might limit their price competitiveness in cost per gigabyte.
This seminar discuss on the Circuits and Device implications for Reliable Flash and Phase Change Memory.
