Organic Antenna-in-Package Designs for Millimeter Wave Applications

#millimeter-waves #Antenna-in-package #switched-beam #patterns #dual-polarized #antennas

There is an increasing demand for low-cost millimeter-wave (mmWave) systems that operate in the 60, 77 GHz, and recently 28 GHz bands for Gbps data rate communication and imaging applications. Typical applications in the 60 GHz band demanding Gbps data rates include wireless gigabit Ethernet and wireless uncompressed high-definition video. Large available spectrums, short wavelengths, and the ability to operate in dusty and foggy conditions have made mmWave frequencies at 77 and 94 GHz attractive for radar and imaging applications. Significant momentum has started to build around the 5G wireless communication technologies. The objectives for developing 5G cellular networks include higher capacity, higher data rate, lower end-to-end latency, massive device connectivity, reduced cost and consistent Quality of Experience provisioning. For 5G radio access infrastructure such as base stations, a key enabling technology is mmWave beam-forming at 28 GHz; this band has emerged as  one of the main bands being deployed for this new mode of mobile communications.. Many of the above-mentioned mmWave systems require phased arrays.

Recent advances in silicon technologies have enabled single chip solutions, making these technologies more commercially attractive. However, for the mmWave market to flourish, not only are low-cost device solutions required, but also low-cost antenna and packaging solutions. The short wavelength at mmWave frequencies allows antennas to be embedded within a package or integrated on a chip. Antenna-in-package (AiP) solutions have been recognized to have advantages over antenna-on-chip solutions in bandwidth, radiation efficiency, and low cost due to RFIC die area usage and design flexibility. The realization of robust, radiation-efficient, and broadband mmWave antennas within a multilayer organic (MLO) substrate is difficult due to assembly, material selection, and manufacturing tolerance challenges.

When designing mmWave AiP for practical applications, one has to consider trade-offs among antenna performance (such as bandwidth, radiation patterns, gains, coupling between antenna elements for array applications, and port isolation for dual-polarized antennas), integration with RF transceivers, packages size that relates to array size, package substrate properties (such as electrical properties and thermo-mechanical compatibility), flexibility of interconnects (antenna feed line and routine, power suppliers, and signal controls), and package material, manufacture and assembly cost. Therefore, the process requires codesign of AiP, RFIC, application board, and even heat sink for relatively large phased arrays.

This talk will discuss the challenges and some solutions related to AiP designs based on 18 years of mmWave research at IBM. More specifically, the talk will cover three design examples. First, a switched beam AiP design at 60 GHz for mobile devices or a dangle for laptop applications. The antenna beam can be pointed to either the broadside direction or end-fire direction. Second, a 64-element dual-polarized AiP design for 94 GHz imaging and communication applications is discussed. The antenna array design enables the tiling of multiple AiP modules to form larger antenna arrays. Finally, a 64-element dual-polarized AiP design at 28 GHz for 5G applications is presented.

It is expected that these AiP design technologies for mmWave phased-array applications will not only impact mmWave 5G mobile communication systems, but also open new opportunities and advance development for imaging and other adaptive multi-function systems.
